Terminal Zebra MC3300x

<h3>MC3300X SPECIFICATIONS</h3> <div> <p><strong><span class="spec-sheet-caption">Physical Characteristics</span></strong></p> </div> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Dimensions</strong></td> <td> <p><u><strong>MC3300x Straight Shooter (45° Scan<br>and 0° Scan): </strong></u><br>7.96 in. L x 2.94 in. W x 1.35 in. D<br>202.2 mm L x 74.7 mm W x 34.5 mm D</p> <p><u><strong>MC3300x Turret/Rotating Head:</strong><br></u>8.79 in. L x 2.94 in. W x 1.35 in. D<br>223.4 mm L x 74.7 mm W x 34.5 mm D</p> <p><u><strong>MC3300x Gun/Pistol:</strong></u><br>7.96 in. L x 2.94 in. W x 6.45 in. D<br>202.6 mm L x 74.7 mm W x 163.9 mm D</p> </td> </tr> <tr> <td><strong>Weight</strong></td> <td> <p><u><strong>MC3300x Straight Shooter (0° Scan):</strong></u><br>15.7 oz./445 g</p> <p><u><strong>MC3300x Turret/Rotating Head:</strong></u><br>16.2 oz./460 g</p> <p><u><strong>MC3300x Gun/Pistol:</strong></u><br>18.4 oz./522 g</p> <p><u><strong>MC3300x (45° Scan):</strong></u><br>15.9 oz./450 g</p> </td> </tr> <tr> <td><strong>Display</strong></td> <td>4-inch (800 x 480) WVGA; color display</td> </tr> <tr> <td><strong>Imager Window</strong></td> <td>Corning Gorilla Glass</td> </tr> <tr> <td><strong>Touch Panel</strong></td> <td>Corning Gorilla Glass touch panel with air gap; supports dual input mode with finger, gloved finger and stylus (conductive stylus sold separately)</td> </tr> <tr> <td><strong>Backlight</strong></td> <td>LED backlit display</td> </tr> <tr> <td><strong>Expansion Slot</strong></td> <td>User accessible MicroSD with 32GB SDHC and up to 512GB SDXC</td> </tr> <tr> <td><strong>Network Connections</strong></td> <td>USB 2.0 High Speed OTG (host/client), WLAN and Bluetooth</td> </tr> <tr> <td><strong>Notification</strong></td> <td>Audible tone, multi-color LEDs</td> </tr> <tr> <td><strong>Keypad</strong></td> <td>Numeric (29 key), Function Numeric (38 key), Alpha Numeric (47 key)</td> </tr> <tr> <td><strong>Voice</strong></td> <td>PTT Express and Workforce Connect PTT Pro (Internal speaker, microphone and Bluetooth wireless headset support)</td> </tr> <tr> <td><strong>Audio</strong></td> <td>Built-in speaker and microphone</td> </tr> <tr> <td><strong>Buttons</strong></td> <td>Two programmable side scan keys</td> </tr> </tbody> </table> <p> </p> <p><strong><span class="spec-sheet-caption">Performance Characteristics</span></strong></p> <div class="tablegrid section"><span id="tablegrid_7149"></span> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>CPU</strong></td> <td>Qualcomm SnapdragonTM 660 octa-core 2.2 GHz</td> </tr> <tr> <td><strong>Operating System</strong></td> <td>Android 10 with Zebra’s Restricted Mode for control over GMS and other services; will support future Android releases</td> </tr> <tr> <td><strong>Memory</strong></td> <td>Worldwide: 4 GB/32 GB Flash<br>China only: 4 GB/16 GB Flash</td> </tr> <tr> <td><strong>Power</strong></td> <td>All models ship with rechargeable Li-Ion, 3.6V, 7000mAh PowerPrecision+ battery; full charge under five (5) hours; hot swap support with temporary WLAN/Bluetooth session persistence<br>Backwards compatibility with MC3300 2740mAh (1X) and 5200mAh (2X) batteries</td> </tr> </tbody> </table> </div> <p> </p> <p><strong><span class="spec-sheet-caption">User Environment</span></strong></p> <div class="tablegrid section"><span id="tablegrid_d335"></span> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Operating Temp.</strong></td> <td>-4° F to 122° F/-20° C to 50° C</td> </tr> <tr> <td><strong>Storage Temp.</strong></td> <td>-40°F to 158°F/-40°C to 70°C</td> </tr> <tr> <td><strong>Humidity</strong></td> <td>5% to 95% RH (Non-condensing)</td> </tr> <tr> <td><strong>Drop Specifications</strong></td> <td> <p>Multiple 6 ft./1.8 m drops to concrete across the operating temperature range per MIL-STD-810G</p> </td> </tr> <tr> <td><strong>Tumble Specifications</strong></td> <td> <p>3,000 3.3 ft. /1.0 m tumbles; meets and exceeds IEC tumble specification</p> </td> </tr> <tr> <td><strong>Sealing</strong></td> <td>IP64</td> </tr> <tr> <td><strong>Vibration</strong></td> <td>Sine: 4g’s peak, 5hz to 2khz,<br>Random: .04g²/hz, 20hz to 2khz</td> </tr> <tr> <td><strong>Thermal Shock</strong></td> <td>-40° F to 158° F/-40° C to 70° C</td> </tr> <tr> <td><strong>Electrostatic Discharge (ESD)</strong></td> <td>+/- 15kV air, +/-8kV contact discharge<br>+/-8kV indirect contact discharge</td> </tr> </tbody> </table> </div> <p><span id="text_97ae"></span>  </p> <div class="col-md-6"> <div><span id="text_faef"></span> <p><strong><span class="spec-sheet-caption">Interactive Sensor Technology (IST)</span></strong></p> </div> </div> <div class="tablegrid section"><span id="tablegrid_f31f"></span> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Motion Sensors<br></strong></td> <td>3-axis accelerometer with MEMS gyroscope</td> </tr> </tbody> </table> </div> <p> </p> <p><strong><span class="spec-sheet-caption">Data Capture</span></strong></p> <div class="tablegrid section"><span id="tablegrid_3601"></span> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Scanning</strong></td> <td> <p><u><strong>MC3300x Brick/Straight Shooter (0° Scan):</strong></u><br>SE965 1D, SE4720/SE4770 2D, SE4850 ERI</p> <p><u><strong>MC3300x Turret/Rotating Head:</strong></u><br>SE965 1D Laser</p> <p><u><strong>MC3300x Gun/Pistol:</strong></u><br>SE965 1D, SE4720/SE4770 2D, SE4850 ERI</p> <p><u><strong>MC3300x (45° Scan):</strong></u><br>SE4770 2D</p> </td> </tr> <tr> <td><strong>Rear Camera</strong></td> <td>13MP color camera with LED flash (optional on Straight Shooter and Turret configurations only)</td> </tr> <tr> <td><strong>NFC</strong></td> <td>Tap to Pair, ISO 14443 Type A and B, Felica and ISO 15693 cards, P2P mode and Card Emulation via Host (HCE) support</td> </tr> </tbody> </table> </div> <p> </p> <p><strong><span class="spec-sheet-caption">Wireless LAN</span></strong></p> <div class="tablegrid section"><span id="tablegrid_91d2"></span> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Radio</strong></td> <td> <p>IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v1/w/mc1; Wi-Fi™ certified; IPv4, IPv6, 2x2 MU-MIMO</p> </td> </tr> <tr> <td><strong>Data Rates</strong></td> <td>5GHz: 802.11a/n/ac — up to 866.7 Mbps<br>2.4GHz: 802.11b/g/n — up to 300 Mbps</td> </tr> <tr> <td><strong>Operating Channels (depending on Regulatory)</strong></td> <td>Channel 1-13 (2412-2472 MHz): 1,2,3,4,5,6,7,8,9,10,11,12,13<br>Channel 36-165 (5180-5825 MHz): 36,40,44,48,52<br>56,60,64,100,104,108,112,116,120,124,128,132,136,140,144,149,153,157,161,165<br>Channel Bandwidth: 20, 40, 80 MHz<br>Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency.</td> </tr> <tr> <td><strong>Security and Encryption</strong></td> <td>WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA31 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA31 Enterprise (AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP and EAP-PWD; WPA31 Enterprise 192-bit Mode (GCMP-256) — EAP-TLS; Enhanced Open (OWE)</td> </tr> <tr> <td><strong>Certifications</strong></td> <td>WFA: 802.11n, 802.11ac, PMF, Wi-Fi Direct, WMM-PS, WMM-AC, Voice Enterprise</td> </tr> <tr> <td><strong>Fast Roam</strong></td> <td>PMKID caching; Cisco CCKM; 802.11r; OKC</td> </tr> </tbody> </table> </div> <p> </p> <p><strong><span class="spec-sheet-caption">Wireless PAN</span></strong></p> <div class="tablegrid section"><span id="tablegrid_f1c8"></span> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Bluetooth</strong></td> <td>Class 2, Bluetooth v5.0 with BR/EDR and Bluetooth Low Energy (BLE) Support</td> </tr> </tbody> </table> </div> <p> </p> <p><strong><span class="spec-sheet-caption">Regulatory</span></strong></p> <div class="tablegrid section"><span id="tablegrid_bbfb"></span> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>EMI/EMC</strong></td> <td>FCC Part 15 Subpart B Class B; ICES 003 Class B; EN 301 489-1; EN 301 489-3; EN 55024; EN 55032 Class B</td> </tr> <tr> <td><strong>Electrical Safety</strong></td> <td>UL 60950-1, CAN/CSA C22.2 No. 60950-1, IEC 60950-1, EN 60950-1</td> </tr> <tr> <td><strong>RF Exposure</strong></td> <td>EU: EN 50364, EN 62369-1, EN 50566, EN 62311<br>USA: FCC Part 2, 1093 OET Bulletin 65<br>Supplement ‘C’<br>Canada: RSS-102</td> </tr> </tbody> </table> <p> </p> </div> <p><strong><span class="spec-sheet-caption">Warranty</span></strong></p> <div class="tablegrid section"><span id="tablegrid_a2e2"></span> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td>Subject to the terms of Zebra’s hardware warranty statement, the MC3330x is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment. For complete warranty statement, please visit:<br><a href="https://www.zebra.com/warranty">https://www.zebra.com/warranty</a></td> </tr> </tbody> </table> </div> <p> </p> <p><strong><span class="spec-sheet-caption">Recommended Services</span></strong></p> <div class="tablegrid section"><span id="tablegrid_d318"></span> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td>Zebra OneCare Essential and Select: Maximize Zebra device availability, device value and operational efficiency with these fully-featured support services that set the industry bar for support.<br>Zebra VisibilityIQ^TM Services: Improve device value with Zebra’s optional VisibilityIQ™ Services. VisibilityIQ gives the data-driven, actionable insight to get the most from your devices, workers and daily tasks. VisibilityIQ™ Foresight aggregates big data onto a single, color-coded, cloud-based pane of glass, translating it into actionable insight to streamline workflow. VisibilityIQ™ DNA provides a view into key DNA tools, and VisibilityIQ™ OneCare® cloud-based dashboard offers visibility into repairs, tech support, software security status and more.</td> </tr> </tbody> </table> </div>
