UHF RFID Sled Reader R6

Be the first to review this product

In stock

SKU

R6-2SE5-UEC

€123.83

SPECIFICATIONS

Physical Characteristics
Dimensions	143 x 76 x 140 mm / 5.63 x 2.99 x 5.51 in.
Weight	Sled Reader: 483g / 17.04oz. Sled Reader with Mobile Case: 453g / 15.98oz. Sled Reader with Customized Holder: 500g / 17.64oz.
Power	Battery specification:5200 mAh Standby: over 70 hours (keeping bluetooth connected) Continuous use: up to 6 hours (UHF reading) Charging time: 3-4 hours (with standard adaptor and USB cable)
Buzzer	Support
Interfaces	USB 3.0 Type-C
Indicator LED	Power, Work, Bluetooth
Size of adapted phone	Sled Reader: Width 68~80 mm, thickness ≤ 22 mm Others: Based on phone case or holder
Product Material	Plastic
Colour	Black

Communication
Bluetooth	Bluetooth 4.0, BLE

Performance
MCU	Cortex-M3 72MHz

UHF RFID
Engine	CM2000-1 module based on Impinj Indy R2000； CM710-1 module based on Impinj E710 (coming soon)
Frequency	920-925 MHz / 902-928 MHz / 865-868 MHz
Antenna	Circular Polarized Antenna (3dBic)
Power	1W (30dBm, support +5~+30dBm adjustable) 2W Optional (33dBm, for Latin America, etc.)
R/W ranges	Up to 10m(open outdoors, Impinj MR6 tag)
Fastest Read Rate	900+ tags/sec
Note	Ranges and rates depend on tags and environment

User Environment
Operating Temp.	-20℃~+50℃
Storage Temp.	-40℃~+70℃
Humidity	5%RH - 95%RH non condensing
Drop Specification	Multiple 1.5 m / 4.9 ft. drops to concrete across the operating temperature range
Tumble Specification	1000 x 0.5 m / 1.64 ft. falls at room temperature
Sealing	IP54 per IEC sealing specifications
ESD	±15 KV air discharge, ±8 KV conductive discharge

Barcode Scanning
2D Imager Scanner	SE2707
1D Symbologies	UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS,etc.
2D Symbologies	PDF417, MicroPDF417, Composite, RSS, TLC- 39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.
Note	*This function is optional

More Information

More Information
Memory options (RAM/Flash)	512MB/2GB(Standard Model)
Printhead resolution	203 dpi
printhead width	2"

File to download:	Chainway_R6_User_Manual.pdf
File to download:	Chainway_R2_R6_Test.apk
File to download:	Chainway_R6-EN.pdf
File to download:	Chainway_R6_Accessiries.pdf
