Terminal ZEBRA TC8300

<div> <p><strong>Physical Characteristics</strong></p> </div> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Dimensions</strong></td> <td>9.17 in. L x 2.99 in. W x 2.52 in. D<br>233 mm L x 76 mm W x 64 mm D</td> </tr> <tr> <td><strong>Weight</strong></td> <td>Base: 17.2 oz./490 g; Package 1: 17.6 oz./500 g</td> </tr> <tr> <td><strong>Display</strong></td> <td>800 x 480 pixels; 4.0 in. diagonal; transflective LCD display; 16.7 Million (24-bit) color support; 400 NITs</td> </tr> <tr> <td><strong>Touch Panel</strong></td> <td>Multi-touch projected capacitive; fingertip (bare or gloved) input; conductive stylus supported (sold separately); Corning® Gorilla® Glass</td> </tr> <tr> <td><strong>Power</strong></td> <td>PowerPrecision+ Lithium ion 7000 mAh with hot swap battery backup</td> </tr> <tr> <td><strong>Notifications</strong></td> <td>Audible tone, multi-color LEDs, vibration</td> </tr> <tr> <td><strong>Keypad</strong></td> <td>On-screen keypad</td> </tr> <tr> <td><strong>Voice and Audio</strong></td> <td>Dual speakers, Bluetooth wireless headset support</td> </tr> </tbody> </table> <p> </p> <p><strong>Performance Characteristics</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>CPU</strong></td> <td>Qualcomm Snapdragon^TM 660 octa-core 2.2 GHz</td> </tr> <tr> <td><strong>Operating System</strong></td> <td>Android 10; upgradebale through A11/R¹</td> </tr> <tr> <td><strong>Memory </strong></td> <td>Base, Condensation Resistant, DPM and Package<br>1 models: 4 GB RAM/32 GB Flash pSLC<br>Package 2 models: 8 GB RAM/128 GB 3D TLC Flash</td> </tr> <tr> <td><strong>Storage</strong></td> <td>SDXC compliant micro SD card slot</td> </tr> <tr> <td><strong>App Development</strong></td> <td>EMDK available through Zebra Support Central Web site</td> </tr> </tbody> </table> <p> </p> <p><strong>User Environment</strong><span id="tablegrid_d335"></span></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Operating Temp.</strong></td> <td>-4° F to 122° F/-20° C to 50° C</td> </tr> <tr> <td><strong>Storage Temp.</strong></td> <td>-40° F to 158° F/-40° C to 70° C</td> </tr> <tr> <td><strong>Humidity</strong></td> <td>5% - 95% non condensing (condensing resistant optional)</td> </tr> <tr> <td><strong>Drop Spec.</strong></td> <td>Multiple 8 ft./2.4 m drop to concrete at room temperature per MIL-STD 810G ; multiple 6 ft./1.8 m drop to concrete across full operating temperature range</td> </tr> <tr> <td><strong>Tumble Spec.</strong></td> <td>2,000 3.3 ft./1 m tumbles</td> </tr> <tr> <td><strong>Sealing</strong></td> <td>IP65</td> </tr> <tr> <td><strong>Vibration</strong></td> <td>4 g’s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random (20 Hz to 2 kHz)</td> </tr> <tr> <td><strong>Thermal Shock</strong></td> <td>-40° F to 158° F/-40° C to 70° C rapid transition</td> </tr> <tr> <td><strong>Scanner Window</strong></td> <td>Corning® Gorilla® Glass</td> </tr> <tr> <td><strong>Electrostatic Discharge (ESD)</strong></td> <td>±20kVdc air discharge; ±10kVdc direct discharge; ±10kVdc indirect discharge</td> </tr> </tbody> </table> <p> </p> <p><strong>Data Capture</strong><span id="tablegrid_21fb"></span></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Scanning Options</strong></td> <td><strong>SE965</strong>: 1D standard range laser scanner<br><strong>SE4750</strong>: 1D/2D medium range omnidirectional imager<br><strong>SE4770</strong>: 1D/2D standard range omnidirectional imager<br><strong>SE4750</strong> <strong>DPM</strong>: Direct Part Mark (DPM) imager<br><strong>SE4850</strong>: 1D/2D extended range imager</td> </tr> <tr> <td><strong>Camera</strong></td> <td>13 MP rear facing autofocus, f/2.4 aperture (optional)</td> </tr> <tr> <td><strong>NFC</strong></td> <td>Tap to Pair, ISO 14443 Type A and B, Felica and ISO 15693 cards, P2P mode and Card Emulation via Host (HCE) support (optional)</td> </tr> </tbody> </table> <p><span id="text_d4f"></span>   <span id="tablegrid_fd13"></span> <span id="text_f8e2"></span>   <span id="tablegrid_655c"></span> <span id="text_c192"></span>   <span id="tablegrid_fa92"></span> <span id="text_70a2"></span>   <span id="tablegrid_41b3"></span> <span id="text_f231"></span>   <span id="tablegrid_8794"></span> <span id="text_9447"></span>   <span id="tablegrid_1e6b"></span></p> <div><span id="text_faef"></span> <p><strong>Zebra Interactive Sensor Technology</strong></p> </div> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Light Sensor</strong></td> <td>Automatically adjusts display backlight</td> </tr> <tr> <td><strong>Motion Sensor</strong></td> <td> <p>3-axis accelerometer, 3-axis gyroscope</p> </td> </tr> <tr> <td><strong>Proximity</strong></td> <td>Sensor for automatic hands-free scanning; magnetic sensor to detect insertion in a cart mount or holster</td> </tr> </tbody> </table> <p> </p> <p><strong>Wireless LAN</strong><span id="tablegrid_3601"></span></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Radio</strong></td> <td>IEEE 802.11a/b/g/n/ac/d/h/i/r/k/w; 2x2 MU-MIMO</td> </tr> <tr> <td><strong>Data Rates</strong></td> <td>5GHz: 802.11a/n/ac — up to 866.7 Mbps<br>2.4GHz: 802.11b/g/n — up to 300 Mbps</td> </tr> <tr> <td><strong>Operating Channels</strong></td> <td>Chan 36 - 165 (5180 - 5825 MHz); Chan 1 - 13 (2412 - 2472 MHz); Actual operating channels/frequencies depend on regulatory rules and certification agency</td> </tr> <tr> <td><strong>Security and Encryption</strong></td> <td>WEP, WPA – TKIP, WPA2- TKIP, WPA2-TKIP AES EAP TTLS, PAP, MSCHAP, MSCHAP v2, PEAPv0-MSCHAPv2, PEAPv1- EAP-GTC, EAP-TLS, EAP-FAST, LEAP, FIPS 140-2 Level 1: Data in Motion and Data at Rest</td> </tr> <tr> <td><strong>Multimedia</strong></td> <td>Wi-Fi Multimedia™ (WMM)</td> </tr> <tr> <td><strong>Certifications</strong></td> <td>WFA (802.11n, WMM-PS, 802.11ac, PMF, WMM-AC, Voice Enterprise, WiFi Direct and WPS 2.0)</td> </tr> <tr> <td><strong>Fast Roam</strong></td> <td>PMKID caching, Cisco CCKM, OKC, 802.11r</td> </tr> <tr> <td><strong>Network Connections</strong></td> <td>Bluetooth; USB 2.0 OTG Host docking interface; 802.11r and 802.11k for enterprise voice roaming included</td> </tr> </tbody> </table> <p> </p> <p><strong>Wireless PAN</strong></p> <table style="width: 100%;" border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td style="width: 20.6521%;"><strong>Bluetooth</strong></td> <td style="width: 78.9855%;">Bluetooth v5.0, Bluetooth Low Energy (BLE)<strong><br></strong></td> </tr> </tbody> </table> <p><span id="text_4a6e"></span>   <span id="tablegrid_f1c8"></span> <span id="text_592f"></span></p> <p><strong>Device Approvals and Compliance</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>TAA (optional on select configurations) </strong></td> <td>Trade Agreement Act optional on select configurations Compliant, FIPS 140-2 (DIM & DAR) support; FIPS 140-2 Level 1: Data in Motion and Data at Rest</td> </tr> </tbody> </table> <p> </p> <p><strong>Environmental Compliance</strong><span id="tablegrid_c568"></span></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td>Environment<br>• RoHS Directive 2011/65/EU; Amendment 2015/863<br>• REACH SVHC 1907/2006<br>A complete list of product and materials compliance, please visit:<br><a href="https://www.zebra.com/environment">www.zebra.com/environment</a></td> </tr> </tbody> </table> <p> </p> <p><strong>Warranty</strong><span id="tablegrid_a2e2"></span></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td>Subject to the terms of Zebra’s hardware warranty statement, the TC8300 is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment. For complete warranty statement, go to:<br><a href="https://www.zebra.com/warranty">http://www.zebra.com/warranty</a></td> </tr> </tbody> </table> <p> </p> <p><strong>Recommended Services</strong><span id="tablegrid_d318"></span></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td> <p>Zebra OneCare Essential and Select: Maximize Zebra device availability, device value and operational efficiency with these fully-featured support services that set the industry bar for support.</p> <p>Zebra Visibility Services — Asset Visibility Services (AVS) and Operational Visibility Service (OVS): Options on any Zebra OneCare support contract, these services deliver the device management data needed to take device uptime, operational efficiency and return on investment to the next level.</p> </td> </tr> </tbody> </table> <p> </p> <p><strong>Footnotes</strong><span id="tablegrid_c911"></span></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td> <p>1. Support for future Android OS released past A11/R, are subject to Qualcomm validation.</p> </td> </tr> </tbody> </table> <p> </p> <p><strong>Mobility DNA</strong><span id="tablegrid_81ec"></span></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td>Mobility DNA solutions help you get more value out of our mobile computers by adding functionality as well as simplifying deployment and management of our mobile devices. Mobility DNA is available on Android only. Features may vary by model and a Support Contract may be required. For more information on these Zebra-only features and for the most recent list of supported apps, please visit:<br><a href="https://developer.zebra.com/mobilitydna">https://developer.zebra.com/mobilitydna</a></td> </tr> </tbody> </table>
