Terminal Zebra MC3200

<h3>SPECIFICATIONS</h3> <p> </p> <p> </p> <p><strong>Physical Characteristics</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Dimensions</strong></td> <td><u>Straight Shooter:</u><br>7.49 in. L x 3.22 in. W x 1.78 in. D 190.4 mm L x 81.9 mm W x 45.2 mm D At grip: 2.40 in. W x 1.35 in. D<br>60.9 mm W x 34.2 mm D<br><u>Rotating Turret:</u><br>8.37 in. L x 3.22 in. W x 1.57 in. D 212.6 mm L x 81.9 mm W x 40.0 mm D At grip: 2.40 in. W x 1.35 in. D<br>60.9 mm W x 34.2 mm D<br><u>Gun:</u><br>7.59 in. L x 3.18 in. W x 6.5 in. D 192.7 mm L x 80.8 mm W x 166 mm D</td> </tr> <tr> <td><strong>Weight (including strap, stylus, and battery)</strong></td> <td><u>Straight Shooter:</u><br>12.88 oz./365 g<br><u>Rotating Turret:</u><br>13.13 oz./372 g (with standard battery)<br><u>Gun:</u><br>18.0 oz./509 g (with extended battery)</td> </tr> <tr> <td><strong>Display</strong></td> <td>3.0 in. color (TFT) (320 x 320) display</td> </tr> <tr> <td><strong>Touch Panel</strong></td> <td>Chemically strengthened glass, resistive touch</td> </tr> <tr> <td><strong>Backlight</strong></td> <td>LED Backlight</td> </tr> <tr> <td><strong>Keypad Options</strong></td> <td>28-key Numeric, 38-key Shifted Alpha, 48-key Alpha-Numeric</td> </tr> <tr> <td><strong>Expansion Slot</strong></td> <td>User accessible Micro SD slot; (supports up to 32 GB microSDHC)</td> </tr> <tr> <td><strong>Notifications</strong></td> <td>LEDs, audio</td> </tr> <tr> <td><strong>Audio</strong></td> <td>Speaker, microphone and headset connector (2.5 mm jack)</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Performance Characteristics</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>CPU</strong></td> <td>Dual core 800 MHz OMAP4 Processor (Standard) or Dual core 1 GHz OMAP4 processor (Premium)</td> </tr> <tr> <td><strong>Operating System</strong></td> <td>Choice of Windows Embedded Compact 7.0 (Standard or Premium) or Android 4.1 (Premium)</td> </tr> <tr> <td><strong>Memory</strong></td> <td>512 MB RAM/2 GB Flash (Standard) 1 GB RAM/4 GB Flash (Premium)</td> </tr> <tr> <td><strong>Power</strong></td> <td>PowerPrecision Li-Ion batteries<br>Two options: High Capacity 4800 mAh or Standard Capacity 2740 mAh (not available on gun form factor)</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>User Environment</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Operating Temp.</strong></td> <td>-4° F to 122° F/-20° C to 50° C</td> </tr> <tr> <td><strong>Storage Temp.</strong></td> <td>-40° F to 158° F/-40° C to 70° C</td> </tr> <tr> <td><strong>Battery Charging Temp.</strong></td> <td>32° F to 104° F/0° C to 40° C</td> </tr> <tr> <td><strong>Humidity</strong></td> <td>10 - 95% non-condensing</td> </tr> <tr> <td><strong>Sealing</strong></td> <td>IP54 per IEC specification</td> </tr> <tr> <td><strong>Drop Specs</strong></td> <td>Multiple 4 ft./1.2 m drops to concrete across the operating tem-perature range, multiple 5 ft./1.5 m drops to concrete at ambient temperature 73° F/23° C; meets and exceeds MIL-STD 810G</td> </tr> <tr> <td><strong>Tumble Specs</strong></td> <td>500 1.64 ft./0.5 m tumbles (1,000 drops) at room temperature per IEC 68-2-32 tumble specifications</td> </tr> <tr> <td><strong>ESD</strong></td> <td>EN61000-4-2; ± 20kV Air discharge, ± 10kV direct discharge, ± 10kV indirect discharge</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Data Capture</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Scanning</strong></td> <td>1D Laser(1): SE965 Standard Range with Adaptive Scanning (all models)<br>1D/2D Imager: SE4750-SR, 4750-MR (Straight Shooter and Gun models only)</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Interactive Sensor Technology (IST)</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Motion-sensor</strong></td> <td>CE7.0/Premium model: 3-axis accelerometer that enables motion-sensing applications on dynamic screen orientation, power management and free-fall detects;<br>Android: 3-axis accelerometer that detects screen rotation</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Applications</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Included Applications</strong></td> <td>Asset Tracker Lite</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Wireless Lan Voice and Data Communications</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Radio</strong></td> <td>IEEE® 802.11a/b/g/n</td> </tr> <tr> <td><strong>Security</strong></td> <td><u>Security Modes:</u><br>Legacy(3), WPA and WPA2 (Personal or Enterprise); 802.1X<br><u>Encryption:</u><br>WEP40/WAP104, TKIP and AES<br><u>Authentication:</u><br>TLS; TTLS (CHAP(3), MSCHAP, MSCHAPv2, PAP or MD5(3)); PEAP (TLS(3), MSCHAPv2, GTC); LEAP; FAST (TLS(3), MSCHAPv2, GTC)<br><u>Other:</u><br>Wi-Fi CCXv4 certified; supports IPv6; FIPS 140-2 certified (Android), Q4-2014 (WinCE)</td> </tr> <tr> <td><strong>Antenna</strong></td> <td>Internal antenna w/diversity</td> </tr> <tr> <td><strong>Data Rate</strong></td> <td>802.11a/g: up to 54 Mbps; 802.11b: up to 11 Mbps; 802.11n: up to 65 Mbps (72 Mbps w/SGI)</td> </tr> <tr> <td><strong>Operating Channels</strong></td> <td>Chan 36-165 (5180 - 5825 MHz), Chan 1-13 (2412-2472 MHz); Actual operating channels/frequencies depend on regulatory rules and certification agency</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Wireless Pan Data and Voice Communications</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>Bluetooth</strong></td> <td>Class II, v2.1 with Enhanced Data Rate (EDR); integrated antenna</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Voice and Audio</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td>PTT (client included); high-quality speakerphone; wireless (Bluetooth) and wired headset support; PTT will support headset and speakerphone mode.</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Network Communications</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td><strong>I/O</strong></td> <td>USB 1.1 Full Speed Host/ Client or RS232</td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Warranty</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td>Subjected to the terms of Zebra's hardware warranty statement, the MC3200 is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment. For complete warranty statement, go to:<br><a href="https://www.zebra.com/warranty">www.zebra.com/warranty</a></td> </tr> </tbody> </table> <p> </p> <p> </p> <p><strong>Recommended Services</strong></p> <table border="1" width="100%" cellspacing="0" cellpadding="1"> <tbody> <tr> <td>Zebra OneCare Select; Zebra OneCare Essential</td> </tr> </tbody> </table>
